SINOTRUK HOWO TRACTOR 6x4, 6x2, 4x2 SPECIFICATIONS & PRICES.



PAGE BRIEFING:

SINOTRUK HOWO 4X2 TRACTOR SPECIFICATIONS & PRICE

SINOTRUK HOWO 6X2 TRACTOR SPECIFICATIONS & PRICE

SINOTRUK HOWO 6X4 TRACTOR SPECIFICATIONS & PRICE



Help you find the catalogs ↑↑



SINOTRUK HOWO TRACTOR SPECIFICATIONS & PRICES.


HOWO 4x2  300HP  TRACTOR
 FOB SHANGHAI  US$  37,4500/set
SPECIFICATION
Engine Make: SINOTRUK
Disel:4-Stroke direct injection diesel engine
Engine model: Euro III,WD615.97C
6-cylinder in-line with water cooling, turbo-charging and intercooling
Maximum output:300hp at 1900 rpm according to DIN
Maximum torque:1340Nm at 1200-1500 rpm
Displacement:9.726L
Bore:126mm
Stroke:130mm
Compression ratio:17:1
Specific fuel consumption:195g/kWh
Engine oil filling quantity:23L
Cooling system filling quantity(long-term filling):40L
Thermostat with 71℃ opening begin
Twin cylinder air compressor
Clutch Single-plate dry coil-spring clutch, diameter 430mm,
hydraulically operating with air assistance.
Transmission HW13710CL,  10 forward, 1 reverse
Propeller Shaft Double universal joint propeller shaft with gear-shaped coupling flange
Front Axle Steering with double T-cross section beam
Rear Axles Pressed axle housing, central single reduction with planetary wheel reduction
and with differential lock
Chassis Frame: U-profile parallel ladder frame with section of 300×80×8mm and reinforced
subframe, all cold riveted cross members. Aluminum fuel tank: 300 L capacity with
locking fuel cap, fitted to the off side of the chassis
Steering ZF power steering, model ZF8098,hydraulic steering with power assistance.
Ratio: 22.2-26.2
Braking System Service brake: dual circuit compressed air brake
Parking brake(emergency brake):spring energy, compressed air operating on rear wheels
Auxiliary brake: engine exhaust valve brake
Tyres 295/80R22.5, 7pics
Cab HW76 Cab, one berth, all steel forward control, 55°hydraulically tiltable to the front, 2-arm
windscreen wiper system with three speeds, laminated windscreen with casted-in radio aerial,
hydraulically damped adjustable driver’s seat and rigid adjustable co-driver’s seat,
with heating and ventilating system, exterior sun visor, adjustable roof flap, stereo
radio/cassette recorder, safety belts, adjustable steering wheel, air horn, with 4-point support
fully floating suspension + shock absorbers
Electrical System Operating voltage:24V,negative grounded
Starter:24V.7.5Kw
Alternator:3-phase,28V,1500W
Batteries:2*12V,165Ah/180Ah
Cigar-lighter, horn, headlamps, fog lights, brake lights, indicators and reverse light
Instrument Active check central controller with indicators, with this integral instrument the daily manual checks
on the vehicle and combined indicators of compressed air pressure, coolant temperature, engine oil
pressure and battery charging.
Dimensions in mm Wheel base                                                        3500
Overall length                                                      6110
Overall width                                                       2496
Overall height                                                      3668
Weight in kg Dead weight                                                        7100
Front axle loading capacity                                 6500
Rear axle loading capacity                                 11500
Performance Maximum driving speed(km/h)                           80
Fuel consumption(L/100km)                              30-33



Help you find the catalogs ↑↑


SINOTRUK HOWO TRACTOR SPECIFICATIONS & PRICES.


HOWO 6x2  300HP  TRACTOR
FOB SHANGHAI  US$  39,950/set
SPECIFICATION
Engine Make: SINOTRUK
Disel:4-Stroke direct injection diesel engine
Engine model: Euro III,WD615.97C
6-cylinder in-line with water cooling, turbo-charging and intercooling
Maximum output:300hp at 1900 rpm according to DIN
Maximum torque:1340Nm at 1200-1500 rpm
Displacement:9.726L
Bore:126mm
Stroke:130mm
Compression ratio:17:1
Specific fuel consumption:195g/kWh
Engine oil filling quantity:23L
Cooling system filling quantity(long-term filling):40L
Thermostat with 71℃ opening begin
Twin cylinder air compressor
Clutch Single-plate dry coil-spring clutch, diameter 430mm,hydraulically operating with air assistance.
Transmission HW13710CL,  10 forward, 1 reverse
Propeller Shaft Double universal joint propeller shaft with gear-shaped coupling flange
Front Axle Steering with double T-cross section beam
Rear Axles Pressed axle housing, central single reduction with planetary wheel reduction and with differential lock
Chassis Frame: U-profile parallel ladder frame with section of 300×80×8mm and reinforced subframe, all cold
 riveted cross members
Aluminum fuel tank: 300 L capacity with locking fuel cap, fitted to the off side of the chassis
Steering ZF power steering, model ZF8098,hydraulic steering with power assistance.  Ratio: 22.2-26.2
Braking System Service brake: dual circuit compressed air brake
Parking brake(emergency brake):spring energy, compressed air operating on rear wheels
Auxiliary brake: engine exhaust valve brake
Tyres 295/80R22.5, 9pics
Cab HW76 Cab, one berth, all steel forward control, 55°hydraulically tiltable to the front, 2-arm windscreen
wiper system with three speeds, laminated windscreen with casted-in radio aerial, hydraulically damped
 adjustable driver’s seat and rigid adjustable co-driver’s seat, with heating and ventilating system, exterior
 sun visor, adjustable roof flap, stereo radio/cassette recorder, safety belts, adjustable steering wheel,
air horn, with 4-point support fully floating suspension + shock absorbers
Electrical System Operating voltage:24V,negative grounded
Starter:24V.7.5Kw
Alternator:3-phase,28V,1500W
Batteries:2*12V,165Ah/180Ah
Cigar-lighter, horn, headlamps, fog lights, brake lights, indicators and reverse light
Instrument Active check central controller with indicators, with this integral instrument the daily manual checks on
the vehicle and combined indicators of compressed air pressure, coolant temperature, engine oil pressure
 and battery charging.
Dimensions in mm Wheel base                                                        1800+2500
Overall length                                                      6695
Overall width                                                       2496
Overall height                                                      3835
Weight in kg Dead weight                                                        7600
Front axle loading capacity                                 6500/7000
Rear axle loading capacity                                 11500
Performance Maximum driving speed(km/h)                           102
Fuel consumption(L/100km)                              30-33




Help you find the catalogs ↑↑


SINOTRUK HOWO TRACTOR SPECIFICATIONS & PRICES.


HOWO 6x4  420HP TRACTOR
FOB SHANGHAI  US$  41,600/set
SPECIFICATION
Engine Make: SINOTRUK
Disel:4-Stroke direct injection diesel engine
Engine model:D12.42,Euro III
6-cylinder in-line water cooling, turbocharged with inter cooling, high-pressure common-rail fuel
injection system with maximum pressure of 1600 bar
Maximum output: 420hp at 2200 rpm
Maximum torque:1160Nm at 1100-1600 rpm
Displacement:9.726L
Bore:126mm
Stroke:130mm
Specific fuel consumption:188g/kWh
Clutch Single-plate dry coil-spring clutch, diameter 430mm,hydraulically operating with air assistance.
Transmission HW19712,  12 forward, 2 reverse
Propeller Shaft Double universal joint propeller shaft with gear-shaped coupling flange
Front Axle Steering with double T-cross section beam
Rear Axles Pressed axle housing, central single reduction with planetary wheel reduction and with differential lock
Chassis Frame: U-profile parallel ladder frame with section of 300×80×8mm and reinforced subframe, all cold
riveted cross members
Aluminum fuel tank: 300 L capacity with locking fuel cap, fitted to the off side of the chassis
Steering ZF power steering, model ZF8098,hydraulic steering with power assistance.  Ratio: 22.2-26.2
Braking System Service brake: dual circuit compressed air brake
Parking brake(emergency brake):spring energy, compressed air operating on rear wheels
Auxiliary brake: engine exhaust valve brake
Tyres 12.00/R20, 11pics, radial tyres
Cab HW76 Cab, one berth, all steel forward control, 55°hydraulically tiltable to the front, 2-arm windscreen
 wiper system with three speeds, laminated windscreen with casted-in radio aerial, hydraulically damped
adjustable driver’s seat and rigid adjustable co-driver’s seat, with heating and ventilating system, exterior
sun visor, adjustable roof flap, stereo radio/cassette recorder, safety belts, adjustable steering wheel, air
horn, with 4-point support fully floating suspension + shock absorbers
Electrical System Operating voltage:24V,negative grounded
Starter:24V.7.5Kw
Alternator:3-phase,28V,1500W
Batteries:2*12V,165Ah/180Ah
Cigar-lighter, horn, headlamps, fog lights, brake lights, indicators and reverse light
Instrument Active check central controller with indicators, with this integral instrument the daily manual checks on the
vehicle and combined indicators of compressed air pressure, coolant temperature, engine oil pressure
and battery charging.
Dimensions in mm Wheel base                                                        3225+1350
Front wheel track                                                2022
Rear wheel track                                                 1830
Front overhang                                                    1500
Rear overhang                                                    725
Approach angle(°)                                               16
Departure angel(°)                                               70
Overall length                                                      6800
Overall width                                                       2496
Overall height                                                      2958
Weight in kg Dead weight                                                        8800
Front axle loading capacity                                 7000
Rear axle loading capacity                                 18000/18000
Performance Maximum driving speed(km/h)                           102
Fuel consumption(L/100km)                              30-33
