Specifications: Synchronizers installed; Skew Gears; Rear PTO Available;
Single Middle Shaft; Planetary Mechanism for Deputy Box.
Assembly Type: HW19710T
Category: HW10 Series
Gearbox Type: Manual
Truck Engine Range: From 336hp to 420hp
Number of Forward Gears: 10 Gears
Number of Reverse Gears: 2 Gears
Max Input Torque: 1900 NM
Rated Rotation Speed: 2600 RPM
Weight: 430 KG
Oil/Lubricant Capacity: 15 L
1st Gear Ratio: 14.36
2nd Gear Ratio: 10.66
3rd Gear Ratio: 7.88
4th Gear Ratio: 5.82
5th Gear Ratio: 4.38
6th Gear Ratio: 3.28
7th Gear Ratio: 2.44
8th Gear Ratio: 1.8
9th Gear Ratio: 1.33
10th Gear Ratio: 1
1st Reverse Gear Ratio: 14
2nd Reverse Gear Ratio: 3.2
Shift Type: Single H Type.
Stock Quality: OEM & Original.
Suggested Stock in Repair Shop: 0.5 unit/truck/year.
Suggested Way of Shipping: In 40HQ with other light items.
Urgent Order: Sent by air freight, arrive in 7 days.
Urgency Level when Broken: High.
Note: All inner parts are available, and part numbers are printed on most gears.
