CYLINDER BODY 2#, WD615 EURO-III HOWO PARTS CATALOGS
| CYLINDER BODY 2# | ||
| WD615 EURO-III ENGINE PARTS CATALOGS | ||
| Serial | Name | Part Number |
| 41 | Front gasket | VG1047010038 |
| 44 | Back gasket | VG1047010050 |
| 46 | Gear case | 61557010008 |
| 47 | Bolt | 90003802523 |
| 48 | Bolt | 90003802561 |
| 49 | Bolt | 90003802571 |
| 50 | Spring washer | 90003931122 |
| 51 | Gasket | VG288730061 |
| 52 | Dowel pin | 90003901507 |
| 53 | Gasket | VG61000010134 |
| 54 | Front gasket bracket | VG2600010928 |
| 55 | Joint | VG2600010934 |
| 56 | Bolt | 90011260039 |
| 57 | Spring dowel pin | 90003900085 |
| 58 | Stud | 90003813628 |
| 59 | Stud | 90003813638 |
| 60 | Nut | 90003888453 |
| 61 | Stud | 90003813429 |
| 62 | Stud | 90003813467 |
| 63 | Nut | 90003871252 |
| 64 | Spring washer | 90003932023 |
| 65 | Stud | 90003813447 |
| 66 | Cover | VG2600010830 |
| 66 | Cover | VG1560010069 |
| 67 | Joint | VG14010040 |
| 68 | Stud | 90003813429 |
| 69 | Nut | 90003871252 |
| 70 | Spring washer | 90003932023 |
| 71 | Bolt | 90003802576 |
| 72 | Spring washer | 90003932024 |
| 73 | Cover | VG1500010008A |
| 74 | Joint | VG14010070 |
| 75 | Bolt | 90003862524 |
| 76 | Spring washer | 90003932025 |
| 77 | Stud | 90003813443 |
| 78 | Stud | 90003813429 |
| 79 | Nut | 90003871252 |
| 80 | Spring washer | 90003932023 |
| 81 | Dowel pin | 90003901507 |
| 82 | Nozzle | VG1560010028 |
| 82 | Nozzle | VG1500019039 |
| 83 | Joint | VG14010086 |
| 84 | Bolt | 90003802321 |
| 85 | Spring washer | 90003931082 |
| 131 | Bolt | 90003802442 |
| 132 | Washer | 90003930261 |
| 133 | Support | VG9100590006 |
| 134 | Support | VG9100590009 |
| 135 | Dowel pin | 190003900085 |
