Sinotruk Electrical Diagram - Position Light, Headlamps & Auxiliary High Beams
PDF download below:
| E1 | Left rear position light |
| E2 | Right rear position light |
| E3a | Left front lighting high beam |
| E3b | Left front lighting low beam |
| E4a | Right front lighting high beam |
| E4b | Right front lighting low beam |
| E5 | Left front position light |
| E6 | Right front position light |
| E25L,R | Left and right side marker lights of tractor |
| E30 | Ashtray light |
| E40 | Left auxiliary high beam |
| E41 | Right auxiliary high beam |
| A | Position light |
| B | Headlamps and auxiliary high beams |
| 1 | Battery negative |
| 41 | Ground point on the left side of the cab |
| 42 | Grounding point in the middle of the cab |
| 43 | Grounding point on the right side of the cab |
